NM-2028 NMEA Buffer Distributor Splitter Dual 2 IN / 8 Out

The NM-2028 NMEA distributor has two independent isolated data inputs and can distribute data to up to eight outputs.

The NM-2028 features three operating modes, single mode, dual mode and auto-dual mode.

In single mode, data from one input and distribute it to eight outputs.

In dual mode the distributor can be used as two independent distributor with one input and four outputs.

Auto Switch / Dual Mode: If input NMEA 1 is lost for 30 seconds, the buffer will automatically switches to NMEA input 2. Two independent buffers with 1 input and 4 output signals according to the DIP switch setting.

Order Information

NM-2028-M Manual Mode: 1 Input 4 or 8 Outputs.

NM-2028-MD Manual-Dual Mode: Operate as two independent buffers with 1 input and 4 outputs.

NM-2028-AD Auto Switch / Dual Mode: If input NMEA 1 is lost for 30 seconds, the buffer will automatically switches to NMEA input 2. Two independent buffers with 1 input and 4 output signals according to the DIP switch setting.
